Make your Data Talk!

(Tip #9)

16) You can draw vertical or horizontal lines inn plot by using functions plt.axhline, plt.axvline, or ax.axline, ax.axvline.

H] Be a good storyteller, and convey your findings through a story in a way that is easily understood by masses and gets the message across.

from matplotlib.pyplot import figure
figure(figsize=(10, 7))


vp = plt.violinplot(train_df['target'], vert=False, showmeans=True,
                     showmedians=True)



# Returns a dictionary with keys : ['bodies', 'cbars', 'cmaxes',
#                                   'cmeans', 'cmedians', 'cmins']
# Using these we can tinker with our plot:
vp['bodies'][0].set_edgecolor("k")
vp['bodies'][0].set_linewidth(2)
vp['bodies'][0].set_alpha(1.0)
vp['bodies'][0].set_zorder(10)


vp['cmeans'].set_linestyle(":")
vp['cmeans'].set_color("r")
vp['cmeans'].set_zorder(101)
vp['cmeans'].set_segments(np.array([[[2.06855817, 0.7], [2.06855817, 1.3]]]))



vp['cmedians'].set_linestyle("--")
vp['cmedians'].set_color("orange")
vp['cmedians'].set_zorder(100)
vp['cmedians'].set_segments(np.array([[[1.797, 0.7], [1.797, 1.3]]]))



vp['cbars'].set_zorder(99)
vp['cbars'].set_color("k")
vp['cbars'].set_linewidth(0.5)



vp['cmaxes'].set_visible(False)
vp['cmins'].set_visible(False)



# Legend:
plt.legend(handles=[vp['bodies'][0], vp['cmeans'], vp['cmedians']],
labels=["Target", "Mean", "Median"], handlelength=5)
plt.title("Target Violin Plot")
plt.xlabel("Target")
plt.yticks([])
plt.grid(True, alpha=0.8)

# Adding Text
plt.text(x, y, f"({train_df['target'].median()}) Median",
bbox={'facecolor':'orange', 'edgecolor': 'orange', 'pad':4,
'alpha': 0.7}, zorder=12)
plt.text(x2, y2, f"Mean ({np.round(train_df['target'].mean(),3)})",
bbox={'facecolor':'red', 'edgecolor': 'red', 'pad':4,
'alpha': 0.6}, zorder=11);



Storytelling With Matplotlib (SWMat)

TK Work in Progress...



1) Normal Matplotlib, 2) Seaborn, 3) Matplotlib Power, 4) Storytelling With Matplotlib



5. Multiple Plots



Photo by Ricardo Gomez Angel on Unsplash



You can make as many plots as you need either by using plt.subplots method or manually add Axes's to figure by specifying their box coordinates, or by using plt.GridSpec() method. I.e.

1. Either by using: fig, axess = plt.subplots(ncols=2, nrows=4) and then you can draw in any one of these Axes's by accessing them as axess[col_num][row_rum], and then use any of Axes methods to draw in them.
2. Or by using plt.axes() method giving list of four percent values giving [left, bottom, width, height] of Axes to make in figure. For example: plt.axes([0.1, 0.1, 0.65, 0.65).
3. Or by using plt.GridSpec() method. As grid = plt.GridSpec(n_row, n_col). And now while making Axes by plt.subplot() method you can use this grid as an 2D array to select how many and which grids to use for making current, one, Axes. For example plt.subplot(grid[0,:]) will select whole first row as one Axes. If you want you can leave some of them too.

plt.figure(1, figsize=(10, 8))
plt.suptitle("Hist-Distribution", fontsize=18, y=1)


# Now lets make some axes in this figure
axScatter = plt.axes([0.1, 0.1, 0.65, 0.65])
                # [left, bottom, width, height] in percent values
axHistx = plt.axes([0.1, 0.755, 0.65, 0.2])
axHisty = plt.axes([0.755, 0.1, 0.2, 0.65])



axHistx.set_xticks([])
axHistx.set_yticks([])
axHisty.set_xticks([])
axHisty.set_yticks([])
axHistx.set_frame_on(False)
axHisty.set_frame_on(False)
axScatter.set_xlabel("MedInc  ->")
axScatter.set_ylabel("Population  ->")




# Lets plot in these axes:
axScatter.scatter(x, y, edgecolors='w')
axHistx.hist(x, bins=30, ec='w', density=True, alpha=0.7)
axHisty.hist(y, bins=60, ec='w', density=True, alpha=0.7,
             orientation='horizontal')
axHistx.set_ylabel("")



# Adding annotations:
axScatter.annotate("Probably an outlier", xy=(2.6, 35500),
                   xytext=(7, 28000),
                   arrowprops={'arrowstyle':'->'},
                   bbox={'pad':4, 'facecolor':'orange', 'alpha':
                         0.4, 'edgecolor':'orange'});

(Tip #10)

17) seaborn has its own objects for grids/multiplots namely Facet Grid,Pair Grid and Joint Grid . They have some methods like .map,.map_diag, .map_upper, .map_lower etc that you can look into to draw plots in those locations only in 2D grid.

I] Read the book “Storytelling with data” by Cole N. Knaflic. Its a great read covering every aspect with examples by a well known Data Communicator.

from matplotlib.pyplot import figure
figure(figsize=(10, 8))


sns.jointplot(x, y);





6. Interactive Plots



Photo by Ricardo Gomez Angel on Unsplash

By default Interactive plotting in matplotlib is turned off. That means that plot will be shown to you only after you have given your final plt command or you used a command that triggers plt.draw like plt.show(). You can turn on interactive plotting by ion() function and turn it off by ioff() function. By turning it on every plt function will trigger plt.draw.

In modern Jupyter Notebook/IPython world there is one magic command to turn on Interactive/Animation feature in these notebooks, and that is %matplotlib notebook and to turn it off you can use magic command %matplotlib inline before using any of your plt functions.

matplotlib works with a number of user interface toolkits (wxpython, tkinter, qt4, gtk, and macosx) to show interactive plots. For these interactive plots matplotlib uses event's and event handler/manager (fig.canvas.mpl_connect) to capture some event by mouse or keyboard.

This event manager is used to connect some in-built event-type-looker to a custom function which will be evoked if that particular type of event happens.

There are many events available like ‘ button_press_event’, ‘button_release_event’, ‘ draw_event’, ‘ resize_event’, ‘ figure_enter_event’, etc. which you can connect to like fig.canvas.mpl_connect(event_name, func).

For above example if event_name event happens, all related data to that event will be sent to your function func where you should have coded something to use that data provided. This event data contains information like x and y position, x and y data coordinates, weather click was made inside Axes or not, etc. if they are relevant for your event type event_name.

%matplotlib notebook
# Example from matplotlib Docs

class LineBuilder:
    def __init__(self, line):
        self.line = line
        self.xs = list(line.get_xdata())
        self.ys = list(line.get_ydata())
        self.cid = line.figure.\
                canvas.mpl_connect('button_press_event', self)



    def __call__(self, event):
        print('click', event)
        if event.inaxes!=self.line.axes: return
        self.xs.append(event.xdata)
        self.ys.append(event.ydata)
        self.line.set_data(self.xs, self.ys)
        self.line.figure.canvas.draw()



fig = plt.figure()
ax = fig.add_subplot(111)
ax.set_title('click to build line segments')
line, = ax.plot([0], [0])  # empty line
linebuilder = LineBuilder(line)




# It worked with a class because this class has a __call__
# method.

Random lines drawn using above code (by consecutive clicking)

7. Others

1. 3D Plots
2. Geographical Plots
3. Word Cloud Plots
4. Animations

3D Plots:

3D plots of matplotlib are not in usual lib. It is in mpl_toolkits as matplotlib started with only 2D plots and later on it added 3D plots in mpl_toolkits. You can import it as from mpl_toolkits import mplot3d.

After importing you can make any Axes 3D axes by passing projection='3d' to any Axes initializer/maker function.

ax = plt.gca(projection='3d') # Initialize...

# Data for a three-dimensional line
zline = np.linspace(0, 15, 1000)
xline = np.sin(zline)
yline = np.cos(zline)
ax.plot3D(xline, yline, zline, 'gray')

# Data for three-dimensional scattered points
zdata = 15 * np.random.random(100)
xdata = np.sin(zdata) + 0.1 * np.random.randn(100)
ydata = np.cos(zdata) + 0.1 * np.random.randn(100)
ax.scatter3D(xdata, ydata, zdata, c=zdata, cmap='Greens');

(Tip #11)

18) You can look at 3D plots interactively by running %matplotlib notebook before your plotting functions.

There are many 3D plots available like line, scatter, wireframe, surface plot, contour, bar etc and even subplot is also available. You can also write on these plots with text function.

# This import registers the 3D projection, but is otherwise unused.
from mpl_toolkits.mplot3d import Axes3D


# setup the figure and axes
plt.figure(figsize=(8, 6))
ax = plt.gca(projection='3d')



ax.bar3d(x, y, bottom, width, depth, top, shade=True)
ax.set_title('Bar Plot')

Geographical Plots:

To plot Geographic plots with matplotlib you will have to install another package by matplotlib called Basemap. It is not easy to install, look for official instructions here, or you can use conda command if you have Anaconda installed: conda install -c conda-forge basemap, or if these too doesn’t work for you look here (specifically last comment).

from mpl_toolkits.basemap import Basemap


m = Basemap()
m.drawcoastlines()

You can actually use most of matplotlib’s original functions here like text, plot, annotate, bar, contour, hexbin and even 3D plots on these projections.

And it also has some functions related to geographic plots too like streamplot, quiver etc.

m = Basemap(projection='ortho', lat_0=0, lon_0=0)
# There are a lot of projections available. Choose one you want. m.drawmapboundary(fill_color='aqua')
m.fillcontinents(color='coral',lake_color='aqua')
m.drawcoastlines()


x, y = map(0, 0) # Converts lat, lon to plot's x, y coordinates.


m.plot(x, y, marker='D',color='m')

# llcrnr: lower left corner; urcrnr: upper right corner
m = Basemap(llcrnrlon=-10.5, llcrnrlat=33, urcrnrlon=10.,
            urcrnrlat=46., resolution='l', projection='cass',
            lat_0 = 39.5, lon_0 = 0.)
m.bluemarble()
m.drawcoastlines()

from mpl_toolkits.mplot3d import Axes3D



m = Basemap(llcrnrlon=-125, llcrnrlat=27, urcrnrlon=-113,
             urcrnrlat=43, resolution='i')


fig = plt.figure(figsize=(20, 15))
ax = Axes3D(fig)

ax.set_axis_off()
ax.azim = 270 # Azimuth angle
ax.dist = 6   # Distance of eye-viewing point fro object point



ax.add_collection3d(m.drawcoastlines(linewidth=0.25))
ax.add_collection3d(m.drawcountries(linewidth=0.35))
ax.add_collection3d(m.drawstates(linewidth=0.30))

x, y = m(x, y)
ax.bar3d(x, y, np.zeros(len(x)), 30, 30, np.ones(len(x))/10,
         color=colors, alpha=0.8)

‘Target’ distribution (red -> high) in California. [From above used California Dataset]

Word Cloud Plot:

Word Clouds are used in Natural Language Processing (NLP), showing words having most frequencies, having size depending on their frequency, within some boundary which can be a cloud or not. It plots relative frequency difference between words in data as relative size of their font. It is also easy, most of the times, to get words with highest frequencies just by looking at Word Clouds. But still it is an interesting way to convey data as it is well perceived and easily understood.

There is a python package wordcloud which you can install using pip as pip install wordcloud.

You can first set some properties of WordCloud (like setting a cloud shape using mask parameter, specifying max_words, specifying stopwords etc.) and then generate cloud with specified properties for given text data.

from wordcloud import WordCloud, STOPWORDS



# Create and generate a word cloud image:
wordcloud = WordCloud()\    # Use default properties
             .generate(text)



# Display the generated image:
plt.imshow(wordcloud, interpolation='bilinear')
plt.axis("off")

from PIL import Image
mask = np.array(Image.open("jour.jpg")) # Searched "journalism
                                        # black png" on google
                                        # images...
stopwords = set(STOPWORDS)

wc = WordCloud(background_color="white", max_words=1000, mask=mask,
               stopwords=stopwords)




# Generate a wordcloud
wc.generate(text)



# show
plt.figure(figsize=[20,10])
plt.imshow(wc, interpolation='bilinear')
plt.axis("off")
plt.show()

Animations:

You can easily make animations using matplotlib using one of these two classes:

1. FuncAnimatin: makes an animation by repeatedly calling a function func.
2. ArtistAnimation: Animation using a fixed set of Artist objects.

(Tip #12)

19) Always keep a reference to instance object Animation, otherwise it will be garbage collected.

20) To save an animation to disk use one of Animation.save or Animation.to_html5_video methods.

21) You can speed up/optimize your animation’s drawing by using parameter blit set to True. But if blit=True you will have to return an iterable of artists to be redrawn by init_func.

In FuncAnimation you need to pass atleast current fig and a function which will be called for each frame. Other than that you should also look into parameters frames (iterable, int, generator , None; source of data to pass to func and each frame of animation), init_func (function used to draw a clear frame, otherwise first frame from frames is used), and blit (weather to use blitting or not).

%matplotlib notebook


fig, ax = plt.subplots()
xdata, ydata = [], []
ln, = plt.plot([], [], 'ro')



def init():
    ax.set_xlim(0, 2*np.pi)
    ax.set_ylim(-1, 1)
    return ln,



def update(frame):
    xdata.append(frame)
    ydata.append(np.sin(frame))
    ln.set_data(xdata, ydata)
    return ln,
# Always keep reference to `Animation` obj
ani = FuncAnimation(fig, update, frames=np.linspace(0, 2*np.pi,
                    128), init_func=init, blit=True)

8. Further Reading

1. Storytelling With Data — Cole N. Knaflic (Great book on how to Communicate Data using graphs/charts by a well known Data Communicator)
2. Python Data Science HandBook — Jake VanderPlas
3. Embedding Matplotlib Animations in Jupyter as Interactive JavaScript Widgets — Louis Tiao
4. Generating WordClouds in Python — Duong Vu
5. Basemap Tutorial

9. References

1. Storytelling With Data — Cole N. Knaflic (Great book on how to Communicate Data using graphs/charts by a well known Data Communicator)
2. Python Data Science HandBook — Jake VanderPlas
3. Embedding Matplotlib Animations in Jupyter as Interactive JavaScript Widgets — Louis Tiao
4. Generating WordClouds in Python — Duong Vu
5. Matplotlib Tutorial: Python Plotting — Karlijn Willems
6. Basemap Tutorial
7. Matplotlib Docs
8. Matplotlib mplot3d Toolkit
9. Matplotlib — Interactive
10. Matplotlib — Animations
11. Seaborn Docs

Suggestions and reviews are welcome. Thank you for reading!

Bio: Puneet Grover is a machine learning enthusiast.

Original. Reposted with permission.
